LS-fit STAINLESS STEEL FITTINGS
Features
- The adoption of the Easy Fit mechanism improves the work efficiency.
- The adoption of the AOI’s original sleeve eliminates the tube torsion.
- There is no need to change the sleeve even in use of repetition.
- Degreasing processed.
- The material of main body, nut, and sleeve is SUS316,
that has the outstanding corrosion resistance. - Smooth surface of inner diameter of main body.
- The extensive variations of size allow to fit various tubes.
- Excellent flow characteristics.
Download
Specifications
- Material
-
Body：SUS316、SUS316L
Sleeve：C3604BD
Nut：C3604BD
Back Up Ring：SUS304
- Applicable Tube
-
eco-flex tubes(ecos , ecoh , ecoh(wr))
Fluorine Resin Tubes(FE)
Others Various Tubes
* Please inquire of us about use of nylon tubes.
- Fluid used
-
Air, Water, Chemicals etc.
* Please inquire us for products that use O rings and packing.
Model
| Model No. | Part No. of Standard Type | Applicable Tube O.D.（φ） | Screw Size |
|---|---|---|---|
| LSH-□GNT-SL | Male Connector | 4、6、8、10、12 3.18、4.76、6.35、7.94、9.53、12.7 |
1/4、3/8 |
| LSL-□GNT-SL | Male Elbow | 4、6、8、10、12 3.18、4.76、6.35、7.94、9.53 |
1/4 |
| LSLL-□GNT-SL | Long Male Elbow | 4、6、8、10、4.76、6.35、7.94、9.53 | 1/4 |
| LS40L-□GNT-SL | 40° Male Elbow | 6、8、10 | 1/4 |
| LSH-S□R-SL | Swivel Female Connector | 4、6、8、10、12、16 3.18、4.75、4.76、6.35、7.94、9.53、12.7 |
1/4、3/8 |
| LSL-S□R-SL | Swivel Elbow Connector | 4、6、8、10、12、16 3.18、4.76、6.35、7.94、9.53、12.7 |
1/4、3/8 |
| LSLL-S□R-SL | Swivel Long Elbow Connector | 4、6、8、10、6.35、7.94、9.53 | 1/4、3/8 |
| LSHR-S□R | Swivel R Screw Union | - | 【G(PF)】1/4、3/8 【R(PT)】1/4、3/8 |
| LSHRC-S□R | Swivel RC Screw Union | - | 【G(PF)】1/4、3/8 【Rc(PT)】1/4、3/8 |
| LSES-□SG | Bulkhead Screw Union | - | 1/4、3/8 |
| LSAL-□SG-S□R | Swivel L Screw Union | - | 1/4、3/8 |
| LSAD-□SG-S□R | Swivel D Screw Union | - | 1/4、3/8 |
| LSN-□A-SL | Sleeve Integrated Nut | 4、6、8、10、12 3.18、4.76、6.35、7.94、9.53、12.7 |
- |
：Production on order. Please see the catalog PDF for details.
